General Purpose |
20' GP Container |
40' GP Container |
40' Hi-Cube Container |
Specifications |
8x8'6" Standard |
8x8'6" Standard |
8x9'6" Hi- Cube |
Inside Cubic |
32.8 m3 |
67.2 m3 |
75.9 m3 |
Capacity |
(1,158 cu.ft) |
(2,372 cu.ft) |
(2,679 cu.ft) |
Cargo Capacity |
21,640 kg |
26,500 kg |
26,400 kg |
(47,716 lbs.) |
(58,433 lbs.) |
(58,058 lbs.) |
|
Tare Weight |
2,360 kgs (5,200lbs) |
3,980 kgs (8,776 lbs) |
4150 kgs (9,150 lbs) |
Internal Measurements |
|||
Length |
5.90 m (19.35 ft) |
12.01 m (39.39 ft) |
12.01 m (39.39 ft) |
Width |
2.35 m (7.71 ft) |
2.35 m (7.71 ft) |
2.35 m (7.71 ft) |
Height |
2.38 m (7.80 ft) |
2.38 m (7.80 ft) |
2.69 m (8.82 ft) |
Door Size |
|||
Height |
2.28 m (7.48 ft) |
2.28 m (7.48 ft) |
2.58 m (8.46 ft) |
Width |
2.33 m (7.64 ft) |
2.33 m (7.64 ft) |
2.35 m (7.71 ft) |
Refrigerated & Reefer Containers
| Refrigerated Container | 20'Reefer Container | 40'Reefer Container | 40' Hi-Cube Reefer |
| Specifications | 8x8'6" Standard | 8x8'6" Standard | 8x9'6" Hi- Cube |
| Inside Cubic | 28.3 m3 | 57.8 m3 | 65.8 m |
| Capacity | (1,000 cu.ft) | (2,040 cu.ft) | (2,324 cu.ft) |
| Cargo Capacity | 22,111 kg | 26,120 kg | 28,180 kg |
| (48,746 lbs.) | (57,590 lbs.) | (62,126 lbs.) | |
| Tare Weight | 3290 kgs (7,251 lbs) | 4360 kgs (9,610 lbs) | 4,600 kgs (10,141 lbs) |
| Internal Measurements | |||
| Length | 5.425 m (17'8") | 11.493 m (37'8") | 11.557 m (37'11") |
| Width | 2.275 m (7'5") | 2.270 m (7'5") | 2.286 m (7'6") |
| Height | 2.260 m (7'5") | 2.197 m (7'2") | 2.491 m (8'2") |
| Door Size | |||
| Height | 2.216 m (7'3") | 2.155 m (7'0") | 2.454 m (8'1/2") |
| Width | 2.258 (7'5") | 2.282 m (7'5") | 2.286 m (7'6") |
Open Top Containers
Containers have a top loading facility designed for the carriage of heavy and awkward cargo.
Open top Container |
20' Open Top Container |
40' Open Top Container |
Specifications |
8x8'6" Standard |
8x8'6" Standard |
Inside Cubic Capacity |
32.6 m3 (1,151 cu.ft.) |
66.7 m3 (2,355 cu.ft.) |
Cargo Capacity |
21,700 kg (47,839 lbs.) |
26,530 kg (58.490 lbs.) |
Tare Weight |
2,300 kg (5,071 lbs.) |
3,950 kg (8,170 lbs.) |
Internal Measurements |
||
Length |
5.88 m (19.29 ft.) |
12.01 m (39.39 ft.) |
Width |
2.33 m (7.64 ft.) |
2.33 m (7.64 ft.) |
Height |
2.31 m (7.58 ft.) |
2.31 m (7.58 ft.) |
Door Size |
||
Height |
2.28 m (7.48 ft.) |
2.28 m (7.48 ft.) |
Width |
2.33 m (7.64 ft.) |
2.33 m (7.64 ft.) |
Flat Rack Containers
Containers are designed to carry cargo in excess of the dimensions available in either General purpose or Open top containers.
They consist of a flat bed with fixed ends.
Flat Rack Container |
20' Flat Rack |
40' Flat Rack |
Specifications |
8x8'6" Standard |
8x8'6" Standard |
Cargo Capacity |
20,015 kg (44, 133 lbs.) |
30,476 kg (67,200 lbs.) |
Tare Weight |
3,100 kg (6,835 lbs.) |
6,646 kg (12,450 lbs.) |
Measurement |
||
Length Overall |
5.85 m (19.19 ft.) |
12.05 m (39.52 ft.) |
Width |
2.23 m (7.31 ft.) |
2.12 m (6.95 ft.) |
Height |
2.15 m (7.04 ft.) |
1.96 m (6.43 ft.) |
Platform Containers
Platform Containers are designed to carry cargo in excess of the dimensions available in either General purpose, Open top or Flat Rack containers. They consist of a flat bed with lashing points for securing cargo.
Platform Containers |
20'Platform |
40'Platform |
Specifications |
||
Cargo Capacity |
24,000 kg (52,896 lbs.) |
39,200 kg (86,397 lbs.) |
Tare Weight |
2,750 kg (6.061 lbs.) |
5,800 kg (12,783 lbs.) |
Length Overall |
6.085m (19'11") |
12.90m (40'00") |
Width |
2.438m (8'00") |
2.40m (8'00") |
Height |
2.233m (7'04") |
1.95m (6'5") |
